Product name：Single-use Guide Wire
Product use： Used to assist in cannulation and to aid in bridging difficult strictures during ERCP.
Electronic instruction manual：IFU
Shape | Model | Inch | Max Diameter （mm） | Working Length (mm) | Mandrel Type 【G(ordinary), S(hardened)】 | Turning Function 【blank(ordinary), T(swerve), U(ultrathin sheath)】 |
| Angled | GW-A3526G-T | 0.025 | 0.89 | 2600 | G | T |
| GW-A3545G-T | 0.035 | 0.89 | 4500 | G | T | |
| Straight | GW-S2526G-T | 0.025 | 0.68 | 2600 | G | T |
| GW-S2545G-T | 0.025 | 0.68 | 4500 | G | T | |
| GW-S3526G-T | 0.035 | 0.68 | 2600 | G | T | |
| GW-S3545G-T | 0.035 | 0.68 | 4500 | G | T | |
| Straight Stiff | GW-S2545S-U | 0.025 | 0.63 | 4500 | S | U |
| GW-S2526S-U | 0.025 | 0.63 | 2600 | S | U | |
| GW-S3526S-T | 0.035 | 0.89 | 2600 | S | T | |
| GW-S3545S-T | 0.035 | 0.89 | 4500 | S | T |
